Catheter tube
| Material | PUR ( Polyurethane ) |
|---|---|
| FEP ( Fluorinated Ethylene/Propylene Copolymer ) | |
| ETFE ( Ethylene-tetra?uoroethylene ) | |
| Condition | Coil - Total length can be managed as per customer request. |
| Cut tube - length according to customer specification | |
| Radiopaque stripes | All radiopaque layer |
| All clear type | |
| 3 stripes | |
| 6 stripes |
All radiopaque layer
3 Stripes
6 Stripes
Cut to length Standard Size
Bobbin size / Out side Diameter: Φ400mm x Width: 60mm x Hole Diameter: Φ37mm
| Gauge | OD (mm) | OD tolerance (mm) | ID (mm) | ID tolerance(mm) | Max Length per Coil (PUR) | Max Length per Coil (FEP) | Max Length per Coil (ETFE) |
|---|---|---|---|---|---|---|---|
| 14G | 2.10 | +/-0.04 | 1.60 | +/-0.04 | 300 meter | 300 meter | 300 meter |
| 16G | 1.80 | +/-0.04 | 1.38 | +/-0.04 | 500 meter | 500 meter | 500 meter |
| 17G | 1.50 | +/-0.04 | 1.15 | +/-0.04 | 500 meter | 500 meter | 500 meter |
| 18G | 1.30 | +/-0.04 | 0.95 | +/-0.04 | 700 meter | 700 meter | 700 meter |
| 20G | 1.10 | +/-0.03 | 0.78 | +/-0.03 | 700 meter | 1,000 meter | 1,000 meter |
| 22G | 0.90 | +/-0.03 | 0.62 | +/-0.03 | 1,000 meter | 1,500 meter | 1,500 meter |
| 24G | 0.72 | +/-0.025 | 0.49 | +/-0.025 | 1,000 meter | 1,500 meter | 1,500 meter |
| 26G | 0.60 | +/-0.025 | 0.45 | +/-0.025 | 1,000 meter | 1,500 meter | 1,500 meter |
Cut tube Standard Size
| Gauge | OD (mm) | OD tolerance (mm) | ID (mm) | ID tolerance (mm) | Length (mm) | Tolerance (mm) |
|---|---|---|---|---|---|---|
| 14G | 2.10 | +/-0.04 | 1.60 | +/-0.04 | 30 - 65 | +/-1 |
| 16G | 1.80 | +/-0.04 | 1.38 | +/-0.04 | 30 - 65 | +/-1 |
| 17G | 1.50 | +/-0.04 | 1.15 | +/-0.04 | 30 - 65 | +/-1 |
| 18G | 1.30 | +/-0.04 | 0.95 | +/-0.04 | 30 - 65 | +/-1 |
| 20G | 1.10 | +/-0.03 | 0.78 | +/-0.03 | 30 - 65 | +/-1 |
| 22G | 0.90 | +/-0.03 | 0.62 | +/-0.03 | 30 - 65 | +/-1 |
| 24G | 0.72 | +/-0.025 | 0.49 | +/-0.025 | 30 - 65 | +/-1 |
| 26G | 0.60 | +/-0.025 | 0.45 | +/-0.025 | 30 - 65 | +/-1 |
Item specification is determined according to customer request. (OEM production)
Material: PUR / FEP /ETFE are available. All materials have their own features. Please choose your best option
depending on the intended use. Radiopaque options (All radiopaque layer, All clear tube、3 stripes and 6 stripes)
are also important feature for a catheter tube. Simple reqeuest with size, material, radiopaque preference
and shipping condition becomes a real product in a short term. Try our products with a prototype and feel the good quality!
