Purpose
The machine is intended to automatically cut stainless pipes quickly and accurately in large quantities.
Features
1. The variation in cutting size is extremely small, or +/- 0.15mm
2. High throughput
3. Easy maintenance and inspection
Capacity | |
Work dia. | 17 -19mm dia. shrinkage pipe |
Work Number of shrinkage pipes |
Standard: Cutting of two shrinkage pipes (Single pipe cutting can be selectedwith the switch.) |
Cutting length | Standard cutting Cutting is possible from 15mm up to 150mm. Cutting is possible from 15mm up to150mm Long work cutting Cutting is possible up to 180mm Cutting is possible up to 1300mm |
Grinding wheel speed |
3000 rpm, 50Hz/60Hz (standard) |
Cutting length accuracy |
+/- 0.15mm |
Leading particulars | |
Grindstone size | O.D.: 205 - 150mm |
Hole dia.: 25.4mm | |
Thickness: 0.35mm or more | |
Grindstone flange dia | 70mm, 60mm, 50mm (Standard: 60mm) |
Grinding wheel spindle motor | 0.75kW -2P-200V, 50Hz/60Hz |
Trochoid pump | 0.75kW -2P-200V, 50Hz/60Hz (Max. working pressure: 8kg/cm2) |
Coolant pump | 0.4kW-4P-200V, 50Hz/60Hz |
Separator | 1.5kW-4P-200V, 50Hz/60Hz |
Hydraulic oil tank capacity | 100liters |
Coolant tank capacity | 230liters |
Machine weight | Approx. 1400kg |
Machine dimensions | Width: 1810mm Depth: 1400mm Height: 1750mm |
This specification may be changed without a preliminary announcement for improvement
Purpose
The machine is intended to automatically cut stainless pipes quickly and accurately in large quantities.
Features
1. The variation in cutting size is extremely small, or +/- 0.15mm
2. High throughput
3. Easy maintenance and inspection
Capacity | |
Work dia. |
17 -19mm dia. shrinkage pipe |
Work Number of shrinkage pipes |
Standard: Cutting of two shrinkage pipes (Single pipe cutting can be selected with the switch.) |
Cutting length | Standard cutting (Work feed setting <>) Cutting is possible from 15mm up to150mm |
Long work cutting (Work feed setting <<2~9>> ) Cutting is possible up to 1300mm |
|
Grinding wheel speed |
3000 rpm, 50Hz/60Hz (standard) |
Cutting length accuracy |
+/- 0.15mm |
Leading particulars | |
Grindstone size | O.D.: 205 - 150mm |
Hole dia.: 25.4mm | |
Thickness: 0.35mm or more | |
Grindstone flange dia | 70mm, 60mm, 50mm (Standard: 60mm) |
Grinding wheel spindle motor | 0.75kW -2P-200V, 50Hz/60Hz |
Trochoid pump | 0.75kW -4P-200V, 50Hz/60Hz (Max. working pressure: 8kg/cm2) |
Coolant pump | 0.25kW-4P-200V, 50Hz/60Hz |
Separator | 1.5kW-4P-200V, 50Hz/60Hz |
Hydraulic oil tank capacity | 60liters |
Coolant tank capacity | 50liters |
Machine weight | Approx. 500kg |
Machine dimensions | Width: 965mm Depth: 1200mm Height: 1900mm |
